When it comes to optimising the space within your RV, slide-outs are an ingenious invention that extend the living area with ease. Lippert slide-outs are renowned for their reliability and come in two distinct types: Standard and Inverted. Both serve the same fundamental purpose but are designed for different situations and setups.
What are Slide-Outs?
Slide-outs, also known as slide-out rails or slide-out kits, are mechanisms that support and allow the wall of an RV to expand outward, creating additional living space. Slide-out kits generally come as a system that uses a motor to operate and are an essential feature for those looking to maximise their RV’s interior area.
Standard Lippert Slide-Outs
The standard Lippert slide-outs angle downwards and are what many RV enthusiasts might be familiar with. They feature rail kits where the gear rack is positioned to facilitate the slide-out movement in a way that the weight is carried lower, closer to the ground. This is advantageous for RVs where the centre of gravity plays a critical role in the stability of the unit when the slide-out is extended. The standard slide-out rails are often chosen for their traditional design and straightforward installation process.
Standard Slide-Out Parts
If you’re looking to add a slide-out to your RV, these parts are all compatible with a standard setup.
Lippert Slide Out Motor 300:1
The Lippert Slide Out Motor Replacement (Model No. 236575) is a key upgrade for LCI in-wall slide-outs, offering easy installation and a powerful 300:1 gear ratio for smooth operation. It’s designed for quick integration, ensuring a hassle-free enhancement of your RV’s extend-retract functionality.
Lippert Slide Out Standard Bearing Block Kit
The Lippert Slide Out Standard Bearing Block Kit (Model No. 379060) includes both upper and lower bearing blocks designed specifically for LCI in-wall slide-outs, ensuring a smooth glide without plastic shoes. Installation is straightforward with no assembly required, and its unique design features bearing feet that point downwards for optimal performance.
Lippert Slide Out Standard Repair Kit
The Lippert Slide Out Standard Repair Kit (Model No. 366121) offers a comprehensive solution for maintaining LCI in-wall slide-outs, featuring wheels, shoes, foam seal, and all necessary fitting parts. Designed for effortless installation and no assembly, this kit ensures your slide-out operates smoothly with minimal downtime.
Lippert Slide Out Standard Bearing Block Shoe Set (x4)
The Lippert Slide Out Standard Bearing Block Shoe Set (Model No. 238463) includes four shoes for both upper and lower bearing blocks, tailored for LCI in-wall slide-outs. These shoes are designed for easy installation without the need for assembly.
Lippert Slide Out Standard Spur Gear
The Lippert Slide Out Standard Spur Gear (Model No. 238893) features a 16-tooth design, ensuring optimal performance for standard systems. Designed for easy sidewall installation, this gear is a straightforward upgrade or replacement for maintaining the smooth operation of your slide-out.
Lippert Slide Out Standard Rack Repair Kit
This repair kit (Part No. 366154) is designed for the rear of driver’s side slide-outs, offering a comprehensive solution with 2 rails and bearing block repair parts.
Lippert Slide Out Standard Rack Repair Kit – Float Side – Front
This repair kit (Part No. 366156) provides all necessary components, including 2 rails and bearing block repair parts, for the front of driver’s side slide-outs.
Inverted Lippert Slide-Outs
Inverted slide-outs, as the name suggests, feature an upward-angling gear rack. This design is beneficial for RVs with higher ground clearance or those requiring a higher weight distribution. The inverted rail kits are also less susceptible to road debris and damage when because of their elevated position. This makes them particularly suitable for off-road or all-terrain RVs that travel on uneven surfaces where ground clearance is crucial.
Inverted Slide-Out Parts
If you’re looking to add a slide-out to your RV, these parts are all compatible with an inverted setup.
Lippert Slide Out Motor Replacement – 500:1 Inverted with High Torque
The Lippert Slide Out Motor Replacement – 500:1 Inverted with High Torque (Model No. 287298) is a high-performance option designed for LCI in-wall slide-outs. It facilitates smooth and easy extension and retraction of slide-outs, boasting an easy installation process with no assembly needed. This motor enhances the functionality of slide-outs with its high torque and inverted 500:1 gear ratio, ensuring reliable operation.
Lippert Slide Out Inverted Rack Repair Kit – Float Side – Front
This repair kit (Part No. 366159) is designed specifically for the front of driver’s side slide-outs, incorporating an inverted system to aid in water drainage and prevent buildup inside the rails. This kit includes essential bearing block repair parts, ensuring your slide-out operates efficiently and remains in optimal condition.
Lippert Slide Out Inverted Rack Repair Kit – Fixed Side – Rear
The repair kit (Part No. 366158) ensures the rear of driver’s side slide-outs function smoothly, thanks to its inverted system that improves water drainage and prevents internal rail buildup. Complete with bearing block repair parts, this kit is essential for maintaining the health and performance of your slide-out.
Lippert Slide Out Inverted Repair Kit
The Lippert Slide Out Inverted Repair Kit (Part No. 366120) offers a comprehensive set for the maintenance of LCI in-wall slide-outs with an inverted system, featuring wheels, shoes, foam seal, and all necessary fitting parts for a complete repair solution.
Lippert Slide Out Inverted Bearing Block Kit
The Lippert Slide Out Inverted Bearing Block Kit (Part No. 733086) includes a pair of inverted bearing blocks for both upper and lower placements, specifically designed for LCI in-wall slide-outs. This kit ensures easy installation and efficient operation with bearing teeth that point upwards, although it does not come with plastic shoes.
Lippert Slide Out Inverted Spur Gear
The Lippert Slide Out Inverted Spur Gear (Part No. 700612) is a crucial component for the inverted system, featuring a 16-tooth design for optimal efficiency. Its easy installation inside the side wall makes it a straightforward upgrade or replacement, ensuring the smooth operation of your slide-out system.
Interchangeable Slide-Out Parts
This selection of slide-out parts is suitable to be used in either standard or inverted slide-out setups.
Lippert 8 Amp Slide Out Controller
The Lippert 8 Amp Slide Out Controller (Part No. 326876), compatible with C2 version controllers, offers enhanced functionality for your RV’s slide-out system. Featuring intuitive LED indicators and a manual override mode, it ensures straightforward operation. Designed for simple 12V DC power connections and spade connections for switch wiring, this controller is user-friendly and easy to install, making it an ideal upgrade or replacement solution.
Lippert Slide Out Harness
The Lippert Slide Out Harness (Part No. 238991) is specifically crafted for seamless compatibility with Lippert In-Wall Slide-Out systems. It’s a universal component across all Lippert slide-out systems, recognized for its easy installation. This harness ensures reliable electrical connectivity, enhancing the overall performance and reliability of your slide-out operation.
Lippert Slide Out Roller
The Lippert Slide Out Roller (Part No. 320500) is a crucial support accessory designed for Lippert In-Wall Slide-Out systems, ensuring smooth operation and sturdy support. With dimensions of 13.5 cm in length, 4.5cm in width, and 3cm in height, this roller and bracket setup is meant to be installed under the slide-out floor, enhancing the travel and stability of your slide. Its design is universal across all Lippert slide-out systems and is celebrated for its straightforward installation process.
Lippert Slide Out Switch
The Lippert Slide Out Switch (Part No. 117461) is tailored for Lippert In-Wall Slide-Out systems, serving as a vital component for ensuring the smooth operation of RV slide-outs. Featuring a 4-pin style design, this switch is universally applicable across all Lippert slide-out systems and is praised for its straightforward installation process. It plays a key role in facilitating efficient slide-out functionality, making it an indispensable tool for RV owners looking to enhance their mobile living experience with minimal hassle.
Lippert Slide Out Double Wiper Rubber – 4.26m Length
The Double Wiper for Lippert In-Wall Slide-Outs (Part No. 345074) is a key component designed to enhance the functionality and protection of all Lippert slide-out systems. This product is specially crafted for easy installation and is typically mounted along the top and down the sides of a Lippert slide-out to ensure comprehensive coverage. Provided in a pre-packaged length of 4.26 meters, it’s tailor-made to fit the needs of any RV owner looking to maintain the cleanliness and integrity of their slide-out system.
Differences in Usage
While both the standard and inverted Lippert slide-outs perform the same basic function, their usage depends largely on the specific needs of the RV and its expected travel conditions.
- Standard slide-outs are typically used in more traditional RV setups where lower ground clearance is sufficient, and there is a need to keep the weight distribution low. They are ideal for RVs that are used primarily on paved roads and in campgrounds.
- Inverted slide-outs, on the other hand, are better suited for modern RV designs that require a higher ground clearance. They work well for RV enthusiasts who enjoy going off the beaten path and need their slide-out systems to withstand the rigors of rough terrain without getting damaged.
Choosing the Right One for Your RV
When deciding between standard and inverted slide-out systems, consider the following:
- Ground Clearance: If you need higher ground clearance, go for the inverted slide-outs.
- Travel Conditions: For mostly on-road travel, standard slide-outs would suffice. For off-road adventures, inverted slide-outs offer better durability against debris.
- Installation: Standard slide-out kits might offer a more straightforward installation. Check with your manufacturer or installation expert for guidance.
It’s always best to refer to the manufacturer’s recommendations based on your specific RV model. Additionally, ensure that you purchase the appropriate slide-out kits and rail kits designed for either standard or inverted systems to guarantee a perfect fit and proper function.
In conclusion, both the standard and inverted Lippert slide-outs are excellent choices but cater to different needs. Assess your RV’s design, your travel lifestyle, and the conditions you expect to encounter. With the right Lippert slide-outs installed, you can enjoy the expanded living space in your RV, wherever the road may take you.
Expand Your Living Space with Lippert Slide-Outs From RV Spares
If you’re looking to expand the living space in your RV, do so with our selection of Lippert slide-outs. Powerful, durable and easy to install, they’re the perfect way to open up your space and enjoy more room when you’re out on the road. Browse our selection of slide-out parts today, including motors, harnesses, and standard and inverted repair kits, and upgrade your RV today with RV Spares.
